LED 30T Wireless Static And Dynamic Portable Axle Weighing truck scale

FOB Reference Price:Get Latest Price
$200.00 - $495.00 / Piece | 1 Piece/Pieces (Min. Order)
Customization:
Customized logo (Min. Order: 50 Pieces)
Customized packaging (Min. Order: 50 Pieces)

More

Graphic customization (Min. Order: 50 Pieces) Less
Samples:
$495.00 /Piece | 1 Piece (Min. Order) | Buy Samples
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
SAINTBOND
Model Number:
AS021W(2Pcs)
Power Supply:
110V , 220V or according to customer's requirement
Display Type:
LED or LCD
Product Name:
Static And Dynamic Portable Axle Weighing truck scale
Material:
Aluminum-alloy
Custom Design:
Welcome
Service:
OEM&ODM
MOQ:
1pcs per type per capacity
Production Time:
25~45 DAYS
Form of sale:
OEM & ODM Manufacture
Product Certification certification
CE Certified.
Valid from 2018-03-22 until 2049-12-31
Supply Ability
Supply Ability:
8500 Set/Sets per Month
Packaging & Delivery
Packaging Details
Packing of Static And Dynamic Portable Axle Weighing truck scale : Wooden box or case, the size different according to different capacity
Port
Ningbo or Shanghai


LED 30T Wireless Static And Dynamic Portable Axle Weighing truck scale


Type:

WP15CW

Operating Humidity:

≤85%RH under 20

Wireless Frequency:

470MHz

Battery Life:

≥50 hours

Wireless Distance:

Min:800m(Default)

Non-Linearity:

0.01%F.S

A/D Conversion Rate:

≥50times/seconds

Stable Time:

≤5 seconds

Operating Temp. Range:

-20~+80

Citation:

GB/T7551-1997/OIML R60



A/D Conversion Method:

Σ-Δ

Input Signal Range:

-3mV~15mV

Load Cell Excitation:

DC 5V

Max. Connection Number Of Load Cell:

4 at 350 ohm

Load Cell Connection Mode:

4 wire

Verified Counts:

3000

Max. External Counts:

15000

Division:

1/2/5/10/20/50 optional

Display:

LCD display with backlight

Clock:

real clock without effect on power off

Wireless Transmission Frequency:

450MHz

Wireless Transmission Distance:

800 meters (in wide place)

Option:

RS232 communication interface

Features:

Light in weight, and convenient transportation.

Integral flat plate construction, high frequency in dynamic response, and high precision.

Applied special treatment, offering high protection class that are suitable for all kinds of environments.

Adopted special material in aero-industry, with good anti-over loading ability.

Assembled with rubber handles, avoided destroying of the handles.

Mounted with connector and protection block, easy for changing of cables.

Completed with dovetail approach, offering tight connection of the approach and the scale.

Easy for loading on/off of the vehicles.

Applications:

Load control and weighing for the vehicles.

Measuring the weight and bary center of aeroplane.

Measuring weight for special purpose.





QQ20190821102445QQ20190821110659QQ20190821110719QQ20190906125246QQ20190906125230QQ20190906125302
